35-Amp 3-Phase Bridge Rectifier

This is a 35-Amp 3-Phase bridge rectifier that converts three-phase AC voltage to DC voltage. This unit is perfect for smaller generators that put out 35 Amps or less. This includes 3-Phase AC motors which are often used to make wind generators!

• Will work on all battery banks
• The operating range is 0 to 1,000-Volts
• Will work on AC generators that produce 35-Amps or less
• Spade terminals for easily attaching the input and output wires
• One center mounting hole for easily securing to your heatsink and electrical box

SPECIFICATIONS:

• Repetitive Peak Reverse Voltage (VRRM): 1000 Volts
• Average Rectified Output Current (IO): 35 Amps
• Surge Forward Current (IFSM): 400 Amps
• Peak Forward Voltage (VFM): 1.2 Volts
• Peak Reverse Current (IRRM): 10 uAmps
• Storage Temperature: -40 to +150C
• Junction Temperature (Tj): -40 to +150C
